Print method
Thermal transfer

Resolution
203DPI

Print width
108mm(Max.)

Print speed
152mm/s(Max.)

Memory
SDRAM: 32MB,
Flash:64MB

Print Head Life
50 Km

Sensor
Photoelectric sensor

TPH temperature detection
Thermistor

TPH position detection
Microswitch

Interface
USB + Serial + Ethernet

CPU
32bit RISC MCP

Barcodes
1D: Code39,Code93,Codabar,Code128(Subsets A, B, and C),
EAN-13,EAN-8,UPC-A,UPC-E,UP􀀀C/EAN Extensions, Planet Code,
Standard 2 of 5,Industrial 2 of 5, Interleaved 2 of 5,LOGMARS,
G51 Data Bar(RSS)
2D: PDF 417,MicroPDF417,QR Code,DataMatrix,MaxiCode,
GS1 Composite

Character enlargement/rotation
Rotate (0°, 90°, 180°, 270°) Enlarge (1-10x)

Character set
Character set Vector fonts support stepless scaling
Built in 7 dot matrix fonts and 1 vector font

Graphical
Support users to download dot matrix fonts and vector fonts
Binary non-format bitmap, HEX, PCX, BMP and IMG

Paper type
can be download to FLASH, RAM
Continuous paper, marking paper, label paper, perforated paper

Paper width
118mm (Max.)

Paper roll OD (Max.)
127mm(5 inch)

Paper roll ID
25.4mm(1 inch) /38mm(1.5 inch)

Paper out
Tear off/ Rewind/ Peel off (optional)/Cut (optional)

Paper thickness
0.06-0.25mm

Ribbon length
300m(Max.)

Ribbon ID
12.7mm/25.4mm

Button, Indicators
1 button,2 indicators

Input
100-240V AC, 50-601-b

Output
24V DC, 2.5A

Operation conditions
5-45°C, 20 – 90%RH(40°C)

Storage conditions
-40-60°C, 20 – 93% RH(40°C)

Dimensions
280mm(L) x218mm(VV)x180mm(H)

Weight
About 2.3kg
