TL-WA801N 300Mbps Wireless N Access Point
– 1× 10/100 M Ethernet Port(RJ45) Support Passive PoE
– 9VDC / 0.6A External Power Supply
– 2 Fixed Omni-Directional Antennas
– 300 Mbps at 2.4 GHz Signal Rate
– 2.4 GHz Frequency
Payment Methods
රු9,500.00
රු9,500.00
රු9,700.00
රු9,800.00
රු3,388.33x 3 MonthsFull: රු10,165.00
Out of stock
රු9,500.00
Out Of Stock
Wireless N – Speed & Range
Adopting IEEE 802.11n advanced MIMO (Multi Input Multi Output) technology, it simultaneously works
through two antennas to Tx and Rx to overcome the interference and signal degradation when
traveling long distances or through physical barriers in a small office or a large apartment.
HARDWARE FEATURES
Interface
1× 10/100 M Ethernet Port(RJ45)
Support Passive PoE
Button Power On/Off Button, WPS Button, Reset Button
External Power Supply
9VDC / 0.6A
Wireless Standards
IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
Dimensions ( W x D x H )
7.1 × 5.1 × 1.4 in (181.6 × 129.5 × 36.2 mm)
Antenna
2 Fixed Omni-Directional Antennas
WIRELESS FEATURES
Frequency
2.4 GHz
Signal Rate
300 Mbps at 2.4 GHz
Reception Sensitivity
11g 6Mbps: -90dBm
11g 54Mbps: -77dBm
11n HT20 MC7: -73dBm
11n HT40 MC7: -70dBm
Wireless Modes
AP Mode
Multi-SSID Mode
Client Mode
Range Extender Mode
Wireless Functions
Enable/Disable Wireless Radio, WMM, Short GI, AP
Isolation, Wireless Statistics, Throughput Monitor
Wireless Security
WEP, WPA/WPA2, WPA/WPA2-PSK encryptions
Quality of Service
WMM
Management Features
SNMP
Advanced Features
Up to 30 meters Passive PoE is supported
Transmission Power
CE: <15dBm; FCC: <20dBm
OTHERS
Certification
CE, FCC, RoHS
Package Content
Wireless Access Point TL-WA801N
Power Adapter
Passive PoE Power Injector
RJ45 Ethernet Cable
Quick Installation Guide
System Requirements
Microsoft Windows 98SE/NT/2000/XP/Vista™/7/8/8.1/10, MAC OS,
NetWare, UNIX or Linux
Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other
Java-enabled browser
Cable or DSL Modem
Subscription with an Internet Service Provider (for Internet access)
Environment
Operating Temperature: 0°C~40°C (32°F ~104°F)
Storage Temperature: -40°C~70°C (-40°F ~158°F)
Operating Humidity: 10%~90% RH
Storage Humidity: 5%~90% RH
