Brand	NZXT
Color	White

KEY SPECS

Motherboard Support : Mini-ITX, Micro-ATX, ATX
Enclosure Type : Mid-Tower
Case Material (White) : SGCC Steel, Ultra-clear Tempered Glass
Case Material (Black) : SGCC Steel, Dark Tinted Tempered Glass

DIMENSIONS

Height (With Feet) : 505mm
Height (Without Feet) : 480mm
Width : 230mm
Depth : 480mm
Weight : 10.57kg

COMPATIBILITY & CLEARANCE

Max CPU Cooler Clearance : Up to 185mm
Max GPU Clearance : Up to 400mm
Front Radiator Clearance : 60mm
Top Radiator Clearance : 30mm
Cable Management : 18-22mm
PSU Clearance : Up to 200mm

FRONT I/O PORTS

USB 3.2 Gen 1 Type-A : 2
USB 3.2 Gen 2 Type-C : 1
Headset Audio Jack : 1
EXPANSION SLOTS
Standard : 7
Vertical : 0
DRIVE BAYS
2.5″ : 4+2
3.5″ : 2

FAN SUPPORT

Front : 3 x 120mm / 3 x 140mm (3 x F Series RGB Core 140mm included)
Top : 3 x 120mm / 2 x 140mm
Rear : 1 x 120mm / 1 x 140mm (1 x F Series Quiet 140mm (Case Version) included)
Filters : All Air Intakes

RADIATOR SUPPORT

Front : Up to 360mm with Push/Pull
Top : Up to 360mm
Rear : Up to 140mm

FAN SPECS

Model : F140 RGB Core Fan (Case Version)
Speed : 1200 ± 120 RPM
Airflow : 61.74 CFM
Static : 2.06mm-H2O
Noise : 29.05 dBA
Fan Connector : 3-pin

FAN SPECS

Model : F120Q (Case Version)
Speed : 1200 ± 240RPM
Airflow : 62.18 CFM
Static : 1.05 mm – H2O
Noise : 25.1 dBA
Fan Connector : 3-pin
